LED SMD CHIP

5050 WS2812 + RGB LED SMD chip diode

Feature description Power

• input voltage: 3.5-7.5V OUT R/G/B
• Constant current value: 12mA Top SMD
• internally integrates high-quality external control single-wire serial cascaded constant current IC
• The control circuit and chip are integrated in the SMD 5050 components to form a complete external

control pixel, and the color temperature effect is uniform and consistent high

• Built-in data shaping circuit, after any pixel receives the signal, it will be output after waveform shaping to ensure that the

line waveform distortion will not accumulate

• By default, the light is off after power-on
• Gray scale adjustment circuit (256 levels of gray scale adjustable)
• Data shaping: After receiving the data of this unit, the subsequent data will be shaped and output automatically
• Built-in high-precision and high-stability oscillator.
• Single-line data transmission, unlimited cascading
• High data protocol compatibility
• Data transmission rate: 800Kbps

foggy 3528rgb for Display LED strip module

power:0.2W

Currnet:3*20ma

Wavelength:RGB, Red:620-630nm, Green:520-530nm,Blue 460-470nm,

Voltage:Red:1.8-2.4V, Green:2.8-3.2v, Blue:2.8-3.2v

PLCC4 3528 RGB light-emitting diodes (LEDs) are widely used in various applications and have gained popularity among European and American customers. These LEDs are known for their vibrant colors and energy efficiency.

0.5W 2v 150Ma 5630 Crimson 660nm 665nm 670nm red led diode

Power:0.5W

Current:150mA

Voltage:1.8-2.4V

Wavelength:660-670NM

Overall, the 660nm red light has significant effects on skin health and healing, as well as applications in beauty treatments, medical therapies, and horticulture.
